SunSynk 10KW 48V Single Phase Hybrid Inverter

The SunSynk 10KW 48V Single Phase Hybrid Inverter is a highly efficient power management tool that allows the user to hit those ‘parity’ targets by managing power-flow from multiple sources such as solar, mains power (grid) and generators, and then effectively storing and releasing power as and when utilities require. \n \nApplications \n

\n
• Marine (vessel power management).
\n
• Power shedding (home/office/factory).
\n
• UPS (fuel-saving systems).
\n
• Remote locations with solar and wind generators.
\n
• Building sites.
\n
• Telecommunication.
\n

\nTechnical Specifications Battery Input Data \n

\n
• Battery Type: Lead-acid or Lithium-ion.
\n
• Battery Voltage Range: 40~60V.
\n
• Max. Charging Current: 220A.
\n
• Max. Discharging Current: 220A.
\n
• Charging Curve: 3 Stages/Equalization.
\n
• Charging Strategy for Li-Ion: Battery Self-adaption to BMS.
\n

\nPV String Input Data \n

\n
• Max. DC Input Power: 13000W.
\n
• PV Input Voltage: 370V (125V~500)
\n
• Start-up Voltage: 125V
\n
• MPPT Range: 150V~425V.
\n
• Full Load Dc Voltage Range: 200V-425V
\n
• PV Input Current: 26A+26A+26A+
\n
• Max. PV Isc:44A+44A+44A
\n
• No. of Strings Per MPPT Tracker: 3 / 2+2+2
\n

\nAC Output Data \n

\n
• Rated AC Output and UPS Power: 10000W.
\n
• Max. AC Power: 11000W.
\n
• AC Output Rated Current: 45.5/43.5A
\n
• Max AC Output Current: 50/47.9A
\n
• Max Continuous AC Passthrough: 70A.
\n
• Peak Power (Off Grid): 2 Time of Rated Power, 10 S
\n
• Power Factor Adjustment Range:0.8 Leading to 0.8 Lagging
\n
• Power Factor: 1
\n
• Output Frequency and Voltage: 50 / 60Hz; L/N/PE 220/230Vac
\n
• Grid Type: Split Phase; 2/3 phase, Single Phase
\n
• Total Harmonics Current Distortion (THDi):<3% (of nominal power)
\n
• Current Harmonic Distortion: THD<3% (Linear load<1.5%).
\n
• DC Current Injection:<0.5% In
\n

\nEfficiency \n

\n
• Max. Efficiency: 97.6%.
\n
• MPPT Efficiency: 97.0%.
\n
• Euro Efficiency: 99.9%.
\n

\n

Protection

\n

\n
• Integrated: Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current
\n
• Protection, Output Shorted Protection, Surge Protection
\n
• Over Voltage Category: DC Type II/AC Type III
\n

\n

Certifications and Standards:

\n

\n
• Grid Regulation: VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150
\n
• Safety EMC / Standard: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
\n

\nGeneral Data \n

\n
• Operating Temperature Range -40~60°C, >45°C Derating.
\n
• Cooling: Smart Cooling
\n
• Noise: ≤30 dB
\n
• Communication with BMS RS485; CAN.
\n
• Weight: 32kg.
\n
• Size: 420W×670H×233D mm (Excluding connectors and brackets)
\n
• Protection Degree: IP65.
\n
• Installation Style: Wall-mounted.
\n
• Warranty: 5 years.
\n
